Vacuum Premade Pouch Packaging Machine
Application：
Mainly used for packaging food products such as meat, cheese, seafood, and other perishable items.
Introduction
Parameter
Vacuum Premade Pouch Packaging Machine
Application:
vacuum premade pouch packaging machine is a type of packaging equipment used to fill and seal preformed pouches with products while removing air from the package to create a vacuum seal. These machines are commonly used for packaging food products, such as meat, cheese, seafood, and other perishable items.
Kindly Reminder:
We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packing Exambers:
.png)
.png)
Main features:
●Controled by PLC (based on the EtherCAT bus) and user friendly HMI, offering simple and convenient operation.
●Fully servo-driven, the feeding pusher achieves precise positioning.
●With a 4-station rotary structure, premade pouch picking, opening, loading, and product pushing automatically.
●Servo-controlled pouch gusseting and pressing ensure nice and secure sealing.
●Equipped with detecting sensor, preventing product feeding in case pouch opening failure, stable and reliable.
Technical Parameters:
| Model | GDSZ130-1012 | GDSZ160-1012 | GDSZ210-0810 | GDSZ260-0810 |
|---|---|---|---|---|
| Bagging stations | 10 | 8 | 8 | 8 |
| Vacuumized stations | 12 | 10 | 10 | 10 |
| Packing speed | 70-90 pouches/min | 50-70 pouches/min | 15-55 pouches/min | 15-35 pouches/min |
| Bag size | L 60-180mm W 55-130mm |
L 80-210mm W 80-160mm |
L 120-300mm W 120-210mm |
L160-350mm W160-260mm |
| Machine weight | 1800Kg | 2100Kg | 2300Kg | 2500Kg |
| Machine size | 2210x1740x1710mm | 2260x1760x1690mm | 2410x1860x1730mm | 2710x2180x1770mm |
| General power | 8KW | 8KW | 9KW | 9KW |
| Power supply | 380V / 3Ph / 50Hz | |||
| Air source | 0.8 m3/min | 0.8 m3/min | 1.0 m3/min | 1.0 m3/min |
| Package material | Single layer PE, PE laminated film, nylon, aluminum foil, paper film and other laminated film | |||
